JBL EON618S Subwoofer

Self powered 18″ Subwoofer

Model : JBL-EON-618S




ENQUIRY

Description

JBL EON618S Powered Subwoofer :

System Type : Self powered 18″ Subwoofer

Max SPL Output : 134 dB

Freq. Range (-10 dB) : 31 Hz – 150 Hz

Freq. Response (±3 dB) : 42 Hz – 150 Hz

System Power Rating : 1000W Peak, 500W Continuous

Input Impedance : 22k (balanced)

Bluetooth Integration : Yes

Line input Gain : 0 to 36 dB

Line : +14 dB

LED indicators : Front Power LED (Defeat-able, white) Rear Power LED (White), Bluetooth (Blue), EQ+ (Green) Preset (Green) Signal (Green) Limit (Orange).

Cooling : Passive

AC Power Input : 100-120VAC 50/60Hz; 230-240VAC 50/60Hz

AC Power Consumption : 1/8th Power – 1.14A (Max), 1/4th Power – 1.71A (Max), 1/3rd Power – 2.03A (Max)

LF Driver : 1 x JBL 618H 457mm (18”) woofer with 2” voice coil

Crossover Frequency : Selectable; 80 Hz, 100 hz, or 120 Hz

Suspension/Mounting : M20 Threaded Pole cup

Handles : 2

Grille : Powder coated, Obsidian, perforated steel with acoustically transparent black cloth backing

Mic Inputs : 2

Phantom Power : No

EQ : 3 Parametric EQs + Hi & Lo shelf

Effects : DSP Presets

Inputs : 2 x Balanced XLR-1/4″ combination inputs

Outputs : 2 x male XLR loop thru out

Enclosure : Duraflex coated plywood

Dimensions (mm) (H x W x D) (in) : 582mm x 668mm x 645mm (22.9in x 26.3in x 25.4in)
