AIR 192|4 Audio Interface

  • 24-bit/192kHz resolution for professional recording and monitoring.
  • Hi-Speed USB circuitry gives you the fastest connection, with a class-leading round trip latency of only 2.59ms*.
  • Transparent Crystal™ preamps and ultra-pristine A/D converters for unsurpassed audio recording quality.
  • VU LED meters for dialing in the perfect level.
  • XLR+¼” TRS combo input with dedicated signal circuit and (1) ¼” instrument input with dedicated signal circuit for the most accurate sound available.
  • Stereo ¼” outs; ¼” headphone out with independent level control.
  • Rugged metal chassis; large central control for easy volume adjustment.
  • USB/Direct knob for balancing between the input signal and the computer signal.
  • *Round trip latency is dependent on buffer settings, and computer hardware.



Model : M-AUDIO AIR 192|4




ENQUIRY

Description

M-AUDIO AIR 192|4 Audio Interface :

Mic Input (balanced XLR)

Frequency Response 20 Hz – 20 kHz (+0.1 dB)
Dynamic Range 104 dB (A-weighted)
Signal-to-Noise Ratio 104 dB (+1.0 dBu, A-weighted)
THD+N 0.003%
Preamp EIN -128 dBu (max. gain, 150 Ω source, A-weighted)
Max Input Level +1.5 dBu
Gain Range 55 dB

Line Input 1 (balanced 1/4″ [6.35 mm] TRS)

Frequency Response 20 Hz – 20 kHz (+0.05 dB)
Signal-to-Noise Ratio 101 dB (1 kHz, 4 dBu, A-weighted)
THD+N 0.003%
Gain Range 55 dB

Line Input 2 (unbalanced 1/4″ [6.35 mm] TS)

Frequency Response 20 Hz – 20 kHz (+0.05 dB)
Dynamic Range 100 dB (A-weighted)
Signal-to-Noise Ratio 102 dB (+ 4 dBu, A-weighted)
THD+N 0.004%
Max Input Level 6 dBu
Input Impedance 1 MΩ
Gain Range 24 dB

Main Outputs, L and R (balanced, differential 1/4″ [6.35 mm] TRS

Frequency Response 20 Hz – 20 kHz (+0.06 dB)
Dynamic Range/Signal-to-Noise Ratio 102 dB (A-weighted)
THD+N 0.005%
Max Output Level +7 dBu (1 kHz, -1 DBFS

Headphone Output (impedance-balanced 1/4” [6.35 mm] TRS)

THD+N 0.005% (A-weighted)
Output impedance 10Ω (A-weighted)

General

Power USB bus-powered
Dimensions (W x D x H) 8.0” x 6.0” x 2.76” (20.42 cm x 15.24 cm x 7.0 cm)
Weight 2.0 Ibs. 0.9 kg.
